The Flat Grid D16 2D Modular Welding Table is a professional flat welding platform specially engineered for thin sheet metal fabrication, stainless steel welding, cabinet & enclosure manufacturing. Featuring a standard D16 (Φ16mm) 50×50mm dense grid hole system, this 2D flat welding table provides ultra-precise planar clamping, minimal welding deformation, and full modular flexibility for small-batch, multi-style sheet metal production. Ideal for workshops focusing on 1-12mm thin metal welding, forming, and assembly jobs.
Optimal thickness range: 1-10 mm (cold-rolled steel, stainless steel, and aluminum sheets); capable of handling thin-gauge structural components up to 12 mm.
Typical workpieces: Electrical control cabinets, equipment housings, equipment enclosures/cabinets, stainless steel decorative parts, sheet metal for doors and windows, small brackets, thin-gauge photovoltaic mounting brackets, and medical device sheet metal components.
Processing techniques: MIG welding, TIG welding, spot welding, laser tailored welding, assembly of bent parts, and assembly/welding of stamped components.
Dense-hole Grid Pattern for Multi-point Clamping and Anti-warping
The D16 system features a 50mm hole spacing—offering more clamping points than the D28 (100mm) system. This ensures secure fixation for 1-6mm stainless steel and cold-rolled sheet metal during spot or continuous welding, effectively counteracting thermal stress to prevent buckling (wavy deformation) and dimensional deviation.
Lightweight Platform Ideal for Mass-producing Small Sheet Metal Parts
The 2D welding table assembly is significantly lighter than heavy-duty 3D/D28 welding tables, allowing for flexible repositioning within the workshop. It is perfectly suited for the batch processing of small components such as chassis, cabinets, decorative sheet metal, thin-walled housings for new energy vehicles, and medical device parts.
Modular Fixturing Eliminates the Cost of Custom Jigs
Utilizes universal D16 standard accessories—including quick-locking pins, vertical clamps, angle supports, height blocks, and positioning stops. No mold creation is required for any sheet metal design; tooling can be set up in just 10 minutes. Switching production models requires no new jigs, drastically reducing prototyping and changeover times.
Nitrided, Anti-stick Surface Protects Thin-sheet Finishes from Scratches
Ideal for sheets with high surface quality requirements (such as powder-coated or brushed stainless steel). The smooth, hard nitrided layer allows for easy spatter removal and prevents scratching of painted or bare metal surfaces, thereby reducing the need for rework or grinding.
Get your dedicated quotation for Flat Grid D16 2D Modular Welding Table — Send your inquiry now and let us optimize your sheet metal welding efficiency!
